Brand Name : ECHU
Model Number : PROFINET TYPE A
Certification : CE
Place of Origin : CHINA
MOQ : 300m
Price : USD01-USD1.1/M
Supply Ability : 10000KM/day
Packaging Details : in roll, splint boxes, pallet
Payment Terms : L/C, T/T, Western Union
Industrial Ethernet Cable Profinet Type A
Application:
Speciall designed for PROFINET protocol, it is used in a wide range of industrial Ethernet Applications, such as wiring of machines, equipment, instrucments and control cabinets.
Suitable for fixed applications.
Properties:
The flame retardancy meets the requirements of IEC60332-1-2
It has good anti external electromagnetic inteference ability
Superior transmission performance
The cable has excellet tensile and compressive characteristics
Structure:
Conductor: Solid bare copper conductor
Insulation: PE
Color: White, yellow, blue, orange
Shielding: aluminum foil wrapped and tinned copper braided
Sheath: PVC
Color: green )approximately RAL6018)
Temperature range:
Fixed installation: -15℃-+80℃
Test Voltage:2000V/min(AC)
Characteristic impedance:100+/-15Ω
Minimum bedning radius
Fixed installation: 8D (D=cable diameter)
![]() |
Industrial Ethernet Cable Profinet Type A Images |
